Technical specifications:
| Frequency Response(-5 dB standard) | : | 60 Hz-20K Hz/td> |
| FREQUENCY RESPONSE(-5 dB CUT model) | : | 100Hz-20K Hz |
| MAX. SOUND PRESSURE(single cabinet,1m,free filed) | : | 130 dB |
| DRIVER | : | 1 x 12″Mid woofer driver |
| DRIVER | : | 1 x 6.5″Mid range driver |
| DRIVER(HF) | : | 1.75” voice coil compression driver |
| Power Handling(RMS/peak 10ms) | : | 400RMS 1600WPEAK |
| NOMINAL DISPERSION ANGLE(hor.x vert.) | : | 90°X40° |
| Nominal Impedance | : | 8 Ohms |
Technical specifications:
| Frequency Response(-5 dB standard) | : | 38Hz-130 Hz |
| Frequency Response(-5 dB 100hz model) | : | 38Hz-100 Hz |
| MAX. SOUND PRESSURE(single cabinet,1m,free filed) | : | 131dB |
| DRIVER(LF) | : | 1X18”/4.5” voice coil LF driver |
| Power Handling(RMS/peak 10ms) | : | 150RMS 6000WPEAK |
| Nominal Impedance | : | 8 Ohms |
Technical specifications:
| Frequency Response(-5 dB standard) | : | 60 Hz-18K Hz |
| FREQUENCY RESPONSE(-5 dB CUT model) | : | 100Hz-18K Hz |
| MAX. SOUND PRESSURE(single cabinet,1m,free filed) | : | 128 dB |
| DRIVER(LF) | : | 2X10”/2.5” voice coil LF driver |
| DRIVER(HF) | : | 3” voice coil compression driver |
| Power Handling(RMS/peak 10ms) | : | 400RMS 1600WPEAK |
| NOMINAL DISPERSION ANGLE(hor.x vert.) | : | 75°X15° |
| Nominal Impedance | : | 8 Ohms |
Technical specifications:
| Frequency Response(-5 dB standard) | : | 38Hz-130 Hz |
| Frequency Response(-5 dB 100hz model) | : | 38Hz-100 Hz |
| MAX. SOUND PRESSURE(single cabinet,1m,free filed) | : | 129 dB |
| DRIVER(LF) | : | 1X18”/4” voice coil LF driver |
| Power Handling(RMS/peak 10ms) | : | 900RMS 3600WPEAK |
| Nominal Impedance | : | 8 Ohms |
